IPHONE X CHARGING PORT REPAIR

Charging port is also known as lightning connector. In this article, we use the word lightning connector instead of charging port. This guide provides you the methods through which you can easily replace your iPhone x charging port.

IPHONE X CHARGING PORT REPAIR AT HOME:

Required tools:

For iPhone x charging port repair you need the following tools:

1. Phillips #000 Screwdriver

2. Black Plastic Spudger

3. ESD- Safe Tweezers

4. Pentalobe Screwdriver

5. Suction cup

6. Sim card eject tool

7. Tri-point Y000 screwdriver bit

8. Standoff screwdriver for

9. Opening pick

Required parts:

IPhone x charging port is the only thing you need while repairing.

Steps to follow:

• Opening the iPhone x`s body:

1. One thing you should keep in mind that power off your iPhone whenever you do any repairing operation.

2. Remove the screws that are placed at both sides of the dock connector. Use the pentalobe screwdriver to remove them.

• Disconnecting the display screen from the iPhone x:

3. Then place the suction cup on the screen and pull it upward carefully in order to release the screen from the bottom of the body.

4. Now use the pointed side of the spudger tool and try to loosen the screen from the bottom of the iPhone X.

5. Then slight the inserted flat end of the spudger tool to widen the gap between the display screen and the body of iPhone X.

6. Again slight the spudger toll at the left and right side of the screen to open the screen from all the sides.

7. After doing this pull the suction cup to open the screen accurately.

8. Remove the suction cup.

9. Now further insert the opening pick at the place of spudger tool to break all the remaining adhesive completely.

10. Now open the display screen from the left hand side as you open the cover of your iPhone

11. Now remove the five Y000 screws that are placed on the bracket of the lower display cable by using Phillips screwdriver.

12. Remove that bracket and place it safely aside.

13. Now use the pointed side of the spudger tool to lift the battery connect out from its housing on the logic board.

14. By using the finger nail or the pointed side of the spudger tool pull the two lower display connector from the logic board.

15. Now by using Phillips screwdriver remove the three screws that are placed on the bracket of front panel sensor assembly connector.

16. Remove the bracket.

17. Remove the front panel sensor assembly connector from the logic board by using pointed side of spudger tool.

18. Now you can easily remove the iPhone X display assembly from the body.

• Charging port replacement:

After removing the screen the next thing you do is to replace the charging port that is our main target.

1. Now by using the Philips #000 screwdriver remove the two screws that are placed on the barometric vent

2. Then remove that vent.

3. Then with the help of the spudger tool try to remove the tapic engine connector from its socket that is placed on the logic board.

4. Tapic engine is protected by the three Phillips screws so remove them by using Phillips screwdriver.

5. Then remove the engine.

6. Then remove the one more Philips screw that protects the Wi-Fi diversity antenna component placed at the bottom of the case.

7. Then remove the screws that are placed on the speakers by using a Phillips screwdriver.

8. Now disconnect the two antenna cable connectors from the logic board by pulling it up from its socket.

9. Deroute the cables from the logic board by using tweezers.

10. Now remove the cable from the speaker by using the tweezer.

11. Now push the speaker assembly towards the logic board and try to disconnect it from the rear case.

12. Now remove the speakers easily.

13. Now use the sim card eject tool and remove the sim tray by ejecting it in the hole.

14. Now disconnect the rear face camera by using the flat end of the spudger tool and pry the dual face camera cable connector.

15. Remove the screws that are placed on the rear facing camera bracket and remove the bracket.

16. Remove the camera flash cable connector again by using the pointed end of the spudger tool.

17. Unscrew those two screws that are placed on the upper cable bracket.

18. Remove the bracket.

19. Now removing the Wi-Fi antenna by opening the Phillips screws.

20. After opening the screws remove the top left antenna.

21. Then remove the two Phillips screws that are placed on the top left side of the body of iPhone x.

22. Remove that bracket.

23. Remove the two screws that are placed on grounding bracket by using standoff screwdriver.

24. Now bend the logic board grounding bracket by using the tweezer.

25. Also, remove the lower cable bracket from the logic board by using the pointed side of spudger tool.

26. Then remove the one Phillips and three standoff screws placed at the logic board.

27. Take out the sim card eject plunger from the logic board by pushing it using spudger tool.

28. Now pull up and then out the battery connector from the end side that is placed on the logic board.

29. Now remove the Phillips screws from the lightning connector.

30. Also remove the spring contact that are placed on lightening connector.

31. Again removing the furthermore Phillips screws from the lightning connector.

32. Two stickers that are used to cover the lightning connector on the logic board. Remove them.

33. Further, remove two Phillips screws from the lower side of iPhone x.

34. There are two microphones that are placed on the bottom side of the iPhone x, also remove them.

35. Place the opening pick from the middle side of the iPhone x in order to slide it underneath the lightning connector.

36. Further, slide the opening pick and reach to the end point of the lightning connector.

37. When opening pick passes through the battery then stop sliding.

38. Now pull out the lightning connector from its place.

39. Further, slide the pick under the lightning connector to remove it completely.

40. Now remove the lightning assembly.

41. Place the new lightning port.

• Reassembling:

For reassemble repeat the above process in reverse steps. Screwed all the screws and cable in the same way you disconnect them.
