IPhone X is another stylist invention of the apple. This device is very delicate and sensitive. A slight collision of any hard thing with this device cause a great damage to you. The damage is done to the display screen. Therefore if your iPhone X fall incidentally or collide with an object due to which its display screen is damaged then don`t worry. We provide you the different methods through which you can easily get your iPhone X display screen replacement at home.
Spudger tool
Suction cup
Pentalobe screwdriver
Phillips #000 screwdriver
Tri-point Y000 screwdriver bit
Opening tool
Tweezer
You just need a new iPhone X display screen.
One thing you should keep in mind that power off your iPhone whenever you do any repairing operation.
Remove the screws that are placed at both sides of the dock connector. Use the pentalobe screwdriver to remove them.
Then place the suction cup on the screen and pull it upward carefully in order to release the screen from the bottom of the body.
Now use the pointed side of the spudger tool and try to loosen the screen from the bottom of the iPhone X.
Then slight the inserted flat end of the spudger tool to widen the gap between the display screen and the body of iPhone X.
Again slight the spudger toll at the left and right side of the screen to open the screen from all the sides.
After doing this pull the suction cup to open the screen accurately.
Remove the suction cup.
Now further insert the opening pick at the place of spudger tool to break all the remaining adhesive completely.
Now open the display screen from the left hand side as you open the cover of your iPhone
Now remove the five Y000 screws that are placed on the bracket of the lower display cable by using Phillips screwdriver.
Remove that bracket and place it safely aside.
Now use the pointed side of the spudger tool to lift the battery connect out from its housing on the logic board.
By using the finger nail or the pointed side of the spudger tool pull the two lower display connector from the logic board.
Now by using Phillips screwdriver remove the three screws that are placed on the bracket of front panel sensor assembly connector.
Remove the bracket.
Remove the front panel sensor assembly connector from the logic board by using pointed side of spudger tool.
Now you can easily remove the iPhone X display assembly from the body.
There is the screws that is paced at the back of the display assembly beside infrared camera, remove it by using Y000 screwdriver.
After removing the screw, remove that metal clip that is beneath it if it is not come out with the screw.
Further remove two Y000 screws that are placed on the speaker/sensor assembly.
Now flip over the speaker assembly by using the flat side of the spudger tool.
Now carefully slide the flat side of the spudger tool under the flex cable of microphone.
Separate the microphone by twisting it gently and carefully without damaging the flex cable.
Then slide the spudger tool from left to right under the proximity sensor + flood illuminator module.
Lift the module to get it out.
By using tweezer wiggle the ambient light sensor and lift it out from the display.
After successfully removing the ambient light sensor remove the earpiece and front sensor assembly.
Placed them on the new display screen of iPhone X.
Now use the above procedure in the reverse order to connect all the screws and accessories back to iPhone X OLED screen in order to use it again as before.
Therefore after trying the above process if your iPhone X is still not working properly and you are not successful in repairing the screen then contact Smart Fix. Smart Fix is the best repairing services provider in New York. Our technicians are trained and highly experienced. They provide high quality services to their customers. You can get all the repairing services at your home. No matter where you are technicians will reach your place and repair your device within 60 minutes. They do not carry your iPhone with them. They have all the tools through which they repair your device. Hence if your screen is broken then contact Smart Fix tell them the issue and they will be at your doorstep without wasting any time.
Our technicians provide all the services at reasonable prices. You can get your iPhone X screen replacement at your home at affordable prices. We don`t demand any advance fees. Once your device is repaired then you will pay us. You can pay us through cash or through credit/debit card.
