Iphone 6 plus is one of the most stylish creations of apple. It fulfils all the need of the user and provides those features and speciation that helps you in solving alot of problems. Here we provide you the methods through which you can easily repair your charging port if it is not working properly and don`t accept iphone charger. This guide helps you to fix the problem and you can do iPhone 6 plus charging port replacement within a short time.
HOME REPAIRING OF IPHONE 6 PLUS CHARGING PORT: Repairing iPhone 6 plus at home is not too difficult. You should be confident and follow the following steps accurately.
Pentalobe screwdriver
Suction cup
Tweezer
Phillips #000 screwdriver
Spudger tool
New iPhone 6 plus charging port
Power off your iPhone 6 plus.
Use the pentalobe screw drive to open the screws that are placed on both sides of the dock connector and keep them aside safely.
After removing the screws, place the suction cup on the screen and pull the screen upward.
Then use the spudger tool to further loosen the screen from the bottom side of the iphone 6 plus.
Now open the display screen in such a way that it makes an angle of 90 degrees.
Then remove the five screws that are placed on the metal bracket securing display screen cable connector by using #000 Screwdriver. [Note: keep these screws aside because they are different in sizes and do remember these position of placing so that you can reassemble them easily]
By using the flat end of spudger tool try to disconnect LCD display cable connector and home button cable connector carefully.
Again use the flat end of spudger tool remove the front facing camera connector and digitizer cable connector.
Now you can see that the screen is separated from the body. Keep it aside safely.
First, remove the two screws that are placed on the battery connector bracket. Keep those screws and battery connector bracket aside.
Now use the flat side of spudger tool and remove the charging port cable and fold it to the right side carefully.
Then remove the battery connector by using spudger tool.
Then open those four screws that are placed on the back case of loudspeakers.
Now disconnect the antenna cable from the logic board by using the pointed side of spudger tool.
Now speakers are free, remove them and keep aside.
Remove the two screws that are placed on the vibrator. Keep both screws and vibrator aside.
Open the two screws that are placed on charging port retaining bracket and keep them aside along with retaining bracket.
Also, open those screws that secure the charging port and lie on the lower side of retaining bracket.
Now remove the screw that secure microphone brace. Disconnect the microphone bracket of black colour and place it aside,
Remove the two screws that protect earphone jack.
Now use the flat end of spudger tool and try to lose the microphone from the back case.
Now try to lose the charging port connector by placing the spudger tool under it.
Remove the damaged charging port connector from the back case.
Place the new charging port.
For reassemble repeat the above process in reverse steps. Screwed all the screws and cable in the same way you disconnect them.
