INTRODUCTION:

No doubt all the iPhone models are amazing. Among all the iPhone, iPhone 7 plus consist of amazing features and specification. The most important thing in the iPhone 7 plus is its battery. The battery allows you to use your iPhone 7 plus for a long time. But what if the battery of the iPhone 7 plus is not working properly? What if you charged your phone and the battery drains quickly? You need to do iPhone 7 plus battery replacement. Here are some steps through which you can easily replace your iPhone 7 plus battery at home.

NOW QUICKY DO IPHONE 7 PLUS BATTERY REPLACEMENT AT HOME:

What you need:

1. Pentalobe screwdriver

2. Spudger tool

3. Phillips #000 screwdriver

4. Suction cup

5. New iPhone 7 plus battery

6. Tri-point Y000 screwdriver bit

7. Tweezer

Follow the steps below:

• Open the iPhone 7 plus:

1. First thing you should do is to power off your iPhone 7 plus.

2. Then open the screws that are placed at both sides of the dock connector by using a pentalobe screwdriver.

• Disconnect the screen from the iPhone 7 plus:

3. Then place the suction cup on the screen and pull it upward carefully in order to release the screen from the bottom of the body.

4. Now use the pointed side of the spudger tool and try to loosen the screen from the bottom of the iPhone 7 plus.

5. Then slight the inserted flat end of the spudger tool to widen the gap between the display screen and the body of iPhone 7 plus.

6. Again slight the spudger toll at the left and right side of the screen to open the screen from all the sides.

7. After doing this pull the suction cup to open the screen accurately.

8. Remove the suction cup.

9. Now further insert the opening pick at the place of spudger tool to break all the remaining adhesive completely.

10. Now open the display screen from the left hand side as you open the cover of your iPhone

11. Now remove the four tri-point Y000 screws that are placed on the bracket of the lower connector by using a tri-point Y000 screwdriver.

12. Remove that bracket and place it safely aside.

13. Now use the pointed side of the spudger tool to lift the battery connect out from its housing on the logic board.

14. By using the finger nail or the pointed side of the spudger tool pull the two lower display connector from the logic board.

15. Now by using the Philips #000 screwdriver remove the two screws that are placed on the bracket of front panel sensor assembly connector.

16. Remove the bracket.

17. Remove the front panel sensor assembly connector from the logic board.

18. Now you can easily remove the display assembly from the body of the iPhone 7 plus.

• Removing the old battery:

19. There are two screws that are placed on the barometric vent. Use the Philips #000 screwdriver to open that screws and remove the barometric vent.

20. Now remove the tapic engine connector from the logic board by using the flat end of the spudger tool.

21. Then remove the three screws that connect the tapic engine to the body of iPhone 7 plus. You can do this by using Philips #000 screwdriver.

22. After opening the screws remove that tapic engine.

23. Now peel of the two adhesive strips that are placed at the lower left side of the battery by using the tweezer.

24. After removing the adhesive strips disconnect the old battery from the iPhone 7 plus.

• Reassemble:

25. Repeat the above procedure in the reverse order to fix all the screws and component in the perfect manner so that you can use your iPhone 7 plus.
