No doubt iPhone 7 plus is a very sensitive device. A small amount of water causes a great damage to your iPhone 7 plus. Therefore if your iPhone 7 plus face any water damage then don’t panic. Try the following methods as follows and get rid of iPhone 7 plus water damage without wasting a lot of time.
There are different remedies through which you do iPhone 7 plus water damage at home easily.
When your iPhone 7 plus is drop in the water than quickly take it out from it. After taking it out, power off the device.
Then open all the ports of your iPhone 7 plus. Take out the sim card along with its try and keep them aside, so that they can dry. You should make sure that all the ports are open so that water can get out through them.
Now you try to get the water out from the opening of iPhone 7 plus by shaking the device. You can also use a blow dryer on cool to dry the water. Blowing the air into the ports can also help in making water dry.
Open the iPhone 7 plus.
Remove the logic board by following the steps below:
Before doing any operation with your iPhone 7 plus, the first thing you should do is to power off your device.
Now open the screws that are placed on both sides of the dock connector by using a pentalobe screwdriver.
Then place the suction cup on the screen and pull it upward carefully in order to release the screen from the bottom of the body.
Now use the pointed side of the spudger tool and try to loosen the screen from the bottom of the iPhone 7 plus.
Then slight the inserted flat end of the spudger tool to widen the gap between the display screen and the body of iPhone 7 plus.
Again slight the spudger toll at the left and right side of the screen to open the screen from all the sides.
After doing this pull the suction cup to open the screen accurately.
Remove the suction cup.
Now further insert the opening pick at the place of spudger tool to break all the remaining adhesive completely.
Now open the display screen from the left hand side as you open the cover of your iPhone
Now remove the four tri-point Y000 screws that are placed on the bracket of the lower connector by using a tri-point Y000 screwdriver.
Remove that bracket and place it safely aside.
Now use the pointed side of the spudger tool to lift the battery connect out from its housing on the logic board.
By using the finger nail or the pointed side of the spudger tool pull the two lower display connector from the logic board.
Now by using the Philips #000 screwdriver remove the two screws that are placed on the bracket of front panel sensor assembly connector.
Remove the bracket.
Remove the front panel sensor assembly connector from the logic board
Now eject the sim tray by placing its tool into the sim hole.
When the sim tray is ejected out of the iPhone, remove it.
Disconnect the rear facing camera connector by sing the flat end of the spudger tool.
Now open the two screws by using a Philips #000 screwdriver that are placed on the rear facing camera bracket and remove the bracket. Place the bracket and screws safely so that you can find them easily at the time of reassembling.
Now remove the camera flash cable connector by using the pointed side of the spudger tool.
Remove the screws that protect the upper cable bracket.
Remove the bracket.
Now use the flat end of the spudger tool to remove the upper cable connector.
Now remove the four screws that are placed on the Wi-Fi antenna.
Remove the antenna that are placed at the top left side.
Remove the grounding bracket screws.
With the help of the tweezer bend the grounding bracket.
Pull the two antenna cable connector by using the pointed side of the spudger tool from the logic board.
By using tweezer deroute the cables of the antenna from the metal bracket on the logic board.
Remove the lower cable connector by using the spudger tool.
Remove the four Philips screws.
Move the sim card eject plunger from the logic board by using the pointed side of the spudger tool.
Lift the battery connector from the logic board by using the spudger flat end.
Lift the battery connector till the end of the logic board and remove it out from the body.
Remove the logic board.
After removing the logic board view it that the corrosion is present in it or not.
Observe all its side. As the 80 percent of the logic board is protected by the shield so you are unable to see that covered part where the water damage is happens.
Now put the logic board in 90 percent isopropyl alcohol.
By using the soft brush rub away all the corrosion.
Again rinse it in alcohol and rub.
Let it dry at least for a day.
Reassemble by reversing the opening process.
After trying the above method, if your iPhone 7 plus is still not responding it means that some moisture is still present in the iPhone 7 plus. Another method to dry the iPhone 7 plus is to place the device in silica gel. Silica gel absorb all the water. Therefore to remove the moisture from the iPhone 7 plus, you should keep it in silica gel. There are many companies that sell silica gel packets that absorbs the water from the iPhone.
